PLC Facial Tissue Box Packing Tissue Paper Automatic Machine 80 Boxes/Min

YY-100 Automatic Facial Tissue Box Packing and Sealing Machine

Description

This machine is developed for automatic boxing of facial tissue product. It can connect with facial tissue interfolder and automatic transfer unit as wellas log saw cutting machine to make an automatic facial tissue production line.

The stable production speed can reach 80 boxes/min; Different packing sizes can be finished, it only takes 10-20mins to change to another packing size. Servo paper feeding and PLC control. Equipped with international advanced glue machine(a nozzle of 0.3-0.36mm), the glue spread is little to save your production cost.

Technical Specification

YY-100 Automatic Facial Tissue Box Packing and Sealing Machine
Name	Technical parameters
Carton basis weight	300-400g/㎡
Maximum packing specification	L(100-240)mm×W(100-120)mm×H(20-90)mm
Packing speed	80-100boxes/min
Glue hot melting machine power	2.32KW
Main motor	2.74KW
Total power	5.1KW
Air pressure	0.5-0.8Mpa
Air consumption	120-160L/min
Power supply type	3phase, 4wire, 380V, 50HZ
Machine size	L3250mm×W1650mm×H1800mm Conveyor size: L2000×W660×H1200mm
Machine weight	2100KG
Machine noise	≤80Db
Main performance and features	1. Packing forms such as automatic feeding, box opening, boxing, batch No. printing, glue spreading, box sealing, etc. are adopted. Featured by compact and reasonable structure, simple operation and adjustment. 2. Servo/step motor, Touch screen, PLC control system and man-machine interface display make operation more clear and convenient. With high automation degree, the machine is more user-friendly. 3. The automatic material arranging and conveying mechanism is adopted to facilitate linked production with automatic production line, which can greatly reduce labor cost. 4. The photoelectric eye automatic detection tracking system is adopted. No boxing is made if the bag is empty, so as to save packing materials to the utmost extent. 5. With wide packing range and convenient adjustment, fast switching among various specifications and sizes can be realized. 6. Change of specifications does not need change of molds, but can be realized through adjustment. 7. Automatic stopping is available when the material boxing is not in place, and the main driving motor overload protection device is used, so that the machine is safer and more reliable. 8. According to customer requirements, the upturning type safety protective cover is adopted, which is featured by simple operation and beautiful appearance.
Five innovations of the machine:	1. High output. The stable speed can reach 80 boxes/min. 2. Complete functions. The machine is suitable for various applications such as semi-cover/full-cover, or high paper and low box/low paper and high box. 3. Rapid production. It only takes 10-20 minutes to change the sizes. 4. Convenient operation. It is easy to control the servo paper feeding and PLC control system. 5. Low cost. Use the import glue machine with a nozzle of 0.3-0.36mm is adopted and the glue-spread is little.

After Sale Services

Spare Parts

YouYuan provides around-the-clock parts support to keep your business moving.

24/7 breakdown support
2,600+ part numbers stocked in our warehouse
Expediting for non-stock parts requests
Professional team members dedicated to supporting your parts needs

Installation

We're here to get you started on the right foot.

Complete installation and start-up support
Start-up and calibration support
Training
