Single Plastic Packing Facial Tissue Machine Soft Packing 120packs
per min
Description
YY-T400 Automatic Tissue Paper Packing Machine is developed for fully automatic single-pack packaging of film packaging facial
tissues, kitchen paper, V-fold paper towels, napkin tissues.
Paper arrangement, feeding, bagging, forward movement, paper
hooking, pusher, film pulling, cutting knife, pressing, moving
sealing, lower inserting film, movable edge guide, swing ironing
and intermediate feeding are all servo-driven control methods. It
has the advantages of complete running function configuration, high
use efficiency, simple operation, wide range of specification
adaptation, quick specification conversion, convenient maintenance,
and low use cost.
Technical Specification
| Basic Feature | Desription | Remarks |
| Equipment sorting and feeding mode | Automatic intelligent material feeding | Four-stage intelligent flexible feeding mode |
Design production speed
| 130 Pack/min | Related to packaging specifications
|
Guarantee stable production speed
| ≤120 Pack/min | Related to packaging specifications |
| Tissue length range | 95 mm - 210 mm | |
| Tissue height range | 40 mm - 100 mm | |
| Tissue width range | 80 mm - 100 mm | |
| Spare parts for packaging sizes change | 3 set | Finished product size, beyond the scope can be customized Standard configuration, the specific packaging size specifications
are drawn up by the buyer |
| Equipment size | L 4650 mm W 3760 mm H 1600 mm | |
Equipment weight
| ≤ 2500 KG | |
| Packaging Materials | Double side heat sealing CPP film | |
| Packaging film thickness | 0．04mm-0．05mm | |
Maximum diameter of roll film
| 500mm | |
Roll film paper core diameter
| 76mm | Comply with international common standards |
| Maximum width of roll film | 340mm | |
| Compressed air | Air resource pressure≥ 0.5MPA | The compressed air shall be provided by the buyer as required |
| Cabinet power supply | 380V/50HZ | Comply with international common standards |
Total power
| 16 KW | Servo motor, speed control motor, heating power sum |
| Suitable voltage changes | +/-10% | Comply with international common standards |
| I/O input | 24VDC | Electrical control system control loop input |
| I/O Output | 24VDC | Electrical control system control loop output |
Equipment motion control mode
| Mainly servo motor control
| |
| Equipment color and process | Rice ash, electrostatic spraying paint process | |
Packing mode | Envelope wrapping | Packaging film lap sealing, both sides heat sealing are flat |
| Perforation option |
Linear perforation
| Choose one from the two |
| Three-dimensional wrapping Linear perforation Zipper perforation | Choose one from the two |
Our Production Process and Delivery to Customer
We have our own CNC to do parts machining, and then shot blasting,
we do baking paint for all the parts. Next we start the assembly,
when the machines are finished, we will do the commissioning and
test running. If customer will not come to our factory to check and
approve, we will send machine photos and videos to customer for
confirmation and approval before packaging and shipment.
FAQ
Why should we choose YouYuan as the facial tissue single plastic
packing machine supplier?
YouYuan has been focusing on automatic facial tissue single plastic
packing machine/soft packing machine for more than 10 years. We
have exported automatic facial tissue single plastic packing
machines to a lot of countries such as Mexico, Colombia, USA,
Malaysia, Peru, Bahrain, Poland, Australia, Egypt,etc.
With strict quality requirements for materials, high-precision
processing equipment, production in strict accordance with national
environmental protection standards, strict control of the entire
production process, to ensure that your equipment quality is
excellent and stable, delivery cycle is guaranteed!
We have strong corporate strength, rich experience, good service,
recognition of many customers, choose YouYuan, is your wise choice!
After Sale Services
Spare Parts
YouYuan provides around-the-clock parts support to keep your
business moving.
- 24/7 breakdown support
- 2,600+ part numbers stocked in our warehouse
- Expediting for non-stock parts requests
- Professional team members dedicated to supporting your parts needs
Installation
We're here to get you started on the right foot.
